Baomain Compact Thin Pneumatic Air Cylinder SDA 12-25 12mm Bore M5 Port Double Action

  • $8.69
    Einzelpreis pro


The compact thin cylinder requiring small space for installation, easy maintance and disassembly. It provide with push-in slot for installation of magnet switch, which can fix the magnet switch at any position. The air cylinder, without need to lubrication, suitable for used in the places with small space for installation.

  • Model: SDA 12-25
  • Bore: 12mm
  • Port size: M5
  • Action Type: Double Action
  • Max Presssure: 1.0Mpa
  • Piston Rod External Diameter: 6mm/ 0.24"
  • Mounting Thread Diameter : 4.2mm/ 0.165"
  • Weight: 57g
