Baomain Capacitive Proximity Sensor, Cylindrical M30 Plastic, Sn 15 mm, 2-wire, 220V, NO Contacts, Cable 2 mm BMC-M30S-15AO
Baomain Capacitive Proximity Sensor, Cylindrical M30 Plastic, Sn 15 mm, 2-wire, 220V, NO Contacts, Cable 2 mm BMC-M30S-15AO
Baomain Capacitive Proximity Sensor, Cylindrical M30 Plastic, Sn 15 mm, 2-wire, 220V, NO Contacts, Cable 2 mm BMC-M30S-15AO
Baomain Capacitive Proximity Sensor, Cylindrical M30 Plastic, Sn 15 mm, 2-wire, 220V, NO Contacts, Cable 2 mm BMC-M30S-15AO
Baomain Capacitive Proximity Sensor, Cylindrical M30 Plastic, Sn 15 mm, 2-wire, 220V, NO Contacts, Cable 2 mm BMC-M30S-15AO
Baomain Capacitive Proximity Sensor, Cylindrical M30 Plastic, Sn 15 mm, 2-wire, 220V, NO Contacts, Cable 2 mm BMC-M30S-15AO

Baomain Capacitive Proximity Sensor, Cylindrical M30 Plastic, Sn 15 mm, 2-wire, 220V, NO Contacts, Cable 2 mm BMC-M30S-15AO

Shipping calculated at checkout.
  • Sensor type: Capacitive proximity sensor
  • Product specific application: Detection of insulated or conductive materials
  • Sensor design: Cylindrical M30
  • Detector flush mounting acceptance: Non flush mountable
  • Wiring technique: 2-wire
  • [Sd] sensing range: 8...15 mm
  • [Sn] nominal sensing distance: 15mm
  • Discrete output function: 1 NO
  • Electrical connection: Cable
  • Cable length: 2 m
  • [Us] rated supply voltage: AC 220V
  • Delay response: <10 ms
  • IP degree of protection: IP67 double insulation conforming to IEC 60529
  • [Sa] assured operating distance: 0...11 mm
  • Adjustment zone: 0...17 mm
  • Status LED: 1 LED for output state indication
  • Residual current: <100 mA open state
  • Switching frequency: <150Hz
